Mini Blinds 1 Inch Aluminium Slats Cordless Tilt Wand Control

Raise and lower by hand

Gently lift or lower the bottom rail using the clear handle to position the blind at your preferred height. The spring-assisted mechanism supports smooth movement without a hanging lift-control cord to pull.

Rotate for light and privacy

Turn the clear wand to change the angle of the slats. Open the slats for more daylight and a clearer view, or tilt them closed for greater privacy. The wand adjusts the slats; it does not raise or lower the blind.

Inside Mount

For installation within the window recess.

1. Width: Measure the opening at the top, middle and bottom. Use the narrowest width.
2. Height: Measure from the top inside edge to the sill at the left, center and right. Use the shortest height.
3. Depth: Allow at least 2 in (approximately 50 mm) of usable mounting depth. Check for handles and other obstructions.

Do not subtract this allowance yourself when the default factory deduction is selected.

No Deduction option: Use this when you are supplying the required finished dimensions. Any necessary installation clearance must already be included in your calculations.

Outside Mount

For installation outside the recess, covering the opening.

1. Measure the full window opening you want the blind to cover.
2. Add a total of 1.97 in (50 mm) to the width and a total of 1.97 in (50 mm) to the height, following the measuring guide.
3. Check the proposed coverage and bracket position, including any trim or obstructions, before ordering.

Enter the calculated finished dimensions and select No Deduction to avoid a further factory reduction.

The 1.97 in (50 mm) addition is the total allowance per dimension, not an addition on every side. Check that the final outside-mount size remains within the custom width and height limits.
